For over a decade, GrimmSpeed intercoolers have been the standard for efficient design, low pressure drop, and unmatched heat rejection. Building on that legacy, this front mount intercooler kit was engineered from the ground up to deliver maximum cooling performance with no compromises.
Quick Specs
27” x 11” x 4” Crossflow Core – Bar-and-plate construction optimized for ideal pressure drop and outstanding heat dissipation
Cast Aluminum End Tanks – Engineered for even flow distribution and minimal restriction
Steel Bolt-On Mounting Brackets – Prevents movement while offering adjustability and long-term durability
No Permanent Chassis Modification – Only light bumper trimming required (fog light delete needed for 08–10 bumpers)
Intake Compatible – Works with factory airbox or GrimmSpeed Intake (snorkel removal required)
Pressure Tested in-House – Cleaned, sealed, and verified before shipping
Finish Options – Raw aluminum or satin black powder coat to protect against corrosion and road debris
High-Quality GrimmSpeed Vinyl Badge – Pre-applied and easily removable
No Tune Required – Maintains the same max boost and spool characteristics as stock
Hand-Welded in the USA – Built and inspected in Minneapolis, MN for uncompromising quality
Intercooler Core
The core is the heart of any FMIC system—get it right, and everything else falls into place. Using over a decade of intercooler R&D, GrimmSpeed designed a fully custom cross-flow core tailored specifically for EJ-powered STIs. Internal fin density, external fin geometry, and cast end tanks were optimized together to produce:
Extremely low pressure drop
Outstanding temperature reduction
Consistent performance under all driving conditions
Unlike many front-mount options, this kit retains factory coolant and washer reservoirs and avoids any major chassis modification. The included steel mounting brackets keep the intercooler firmly supported, even under aggressive track driving.
Light bumper trimming is required for the large core, and 2008–10 models will need a fog light delete.
Intercooler Piping
A high-performance core needs equally capable piping. GrimmSpeed’s piping system is constructed from:
.090”-wall, 2.5” 6061 aluminum
Large-radius CNC mandrel bends for smooth, unrestricted airflow
Bead-rolled ends to lock securely into the included 5-ply silicone couplers
Every pipe is finished in a durable powder coat that complements other GrimmSpeed components while also offering corrosion protection. Routing is engineered for OE fitment, allowing you to retain factory accessories with minimal adjustment.
